Car chiller THERMAL - 1400 24V without the electric motor

The cooling unit consists of:
-evaporator / evaporator with dimensions of 1030mm x 640mm x 170mm tall with a turbine fan 24VDC with high efficiency with a plastic housing, expansion valve, Cipla exchanger, valve defrostu
-cold-set of Goodyear hose to connect the compressor, evaporator and condenser
-complete wiring harness (about 6 m) ​​for connecting the control, security, battery, evaporator, condenser, compressor and hose to the driver cabin
-cab-driver (the same model in all units Thermal Master) with dimensions of 155mm x 80mm x 45mm height
-compressor / compressor production TAMA-TM-16HS/Zexel Seltec TM16 with electromagnetic clutch two strips of 13mm to 2A, coil powered by 24V DC
-hose water flow (outflow drain) about 4mb
-set screws evaporator, condenser (reinforced handle), silicone seals, tightening straps and hoses
-control panel with relays and fuses box measuring 150mm x 80mm x 50mm height
-cover strip-aluminum to protect electrical cables and coolant hoses (ca.100cm)
-condenser with two axial fans, solenoid valves, three-way valve, filter drier, dryer, pressure tank, pressure switch, plastic housing, dimensions 1010mm x 480mm x 310mm height

To connect and start the generator is still required:
compressor-mounting kit to the vehicle's engine with the belt and the belt tensioner (we have different models on offer)
-refrigerant R-404a
-professional with the experience and the right tools (from his many years of trouble-free operation depends on aggregate)

There is also the option of heating in the winter for a small fee. Very well even at - 20 ° C.

 See more: http://thermalmaster.co.kr/sub/pd_truck_1400.htm


● Specifications

● Cooling CapacityㆍAmbient 30℃(86F)


 See more:  http://thermalmaster.co.kr/sub/pd_truck_1400.htm

※Specifications are subjected to change without notice.

chiller much more powerful than the well-known manufacturers in the market already Thermo King C-100, C100, C-200, C200, V-200, V200, Carrier Transicold Viento 200, Neos100, Xarios200, Zanotti Z-20, Hwa Sung HT050, HT050RT, HT-050. Comparable power to the cooling and heating units on the market known Thermo King V-300, V300, Carrier Transicold Viento 300, Xarios300, Zanotti Z-30, Z-35, Hwa Sung HT100, HT100RT, HT-100
